![Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof [206-051S]](http://www.bgamarine.com/cdn/shop/files/29828XL.jpg?v=1706235714&width=1500)
Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof [206-051S] 0.2 lb
Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof [206-051S] is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Care information
Care information
Important! Please ensure to inspect this item before making your purchase. We're here to assist you anytime. Feel free to reach out if you have any questions or concerns; we're more than happy to help! Additionally, we offer financing options to make your purchase easier.
Delivery and Shipping
Delivery and Shipping
We're pleased to offer free shipping on all orders within the US. However, for oversize items, an additional shipping fee may apply. We strive to ensure timely and secure delivery of your products, partnering with top shipping services. For any inquiries regarding our shipping policy, feel free to contact our customer service team. Thank you for choosing BGA Marine!
Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof [206-051S]
Panel Seal/Waterproof "A" Frame Magnetic Circuit Breakers
- Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
- Meets all American Boat and Yacht Council (ABYC) Standards for non-ignition protected circuit breakers
- UL Recognized (UL 1077) for use in th USA, and CSA Certified for use in Canada
- Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
- Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)
- Handle Color - Metal with silicon rubber seal
- Maximum Aperage - 50 Amps
- Maximum Voltage/AIC - 32 VDC/2,500 amps with no back-up fuse (ABYC E-11.10.1.5.5)
- Rated Switch Cycles - 10,000 actuations at rated current and voltage
- Electrical Hardware - Hex nut 1/2-32 (supplied with circuit breaker); Lockwasher 1/2" internal tooth (supplied with circuit breaker)
- Optional Boot - Black silicone rubber (P/N 048-015)
Specifications:
- Color: Stainless
- Throw/Pole: SPST
- Box Dimensions: 2"H x 2"W x 2"L WT: 0.2 lbs
- UPC: 602290201404
